Walkie-Talkie/Phone Backpack Signal Jammer/Jamming for Cellphone/VHF/UHF Radio
Description:
This shoulder-mounted high-power signal shield is designed for military portable shields. The total output power is 90W and the shielding distance can reach 100 meters. This model consists of six different shielding segments. The frequency can be customized according to your needs. The regular frequency is 2G3G4GUHFVHFGPS. We can customize the frequency segment according to your specific needs, or customize the shield according to your shielding distance requirements. The power of each road can also be adjusted. The outer casing of this model is military green, and the weight is 13 kilograms. It is also suitable for shoulder-shoulder portable military.
Features:
- light weight backpack that can be carried through difficult terrain without burden.
- Portable jammer built in a backpack Configuration
- Covers wideband frequency range includes VHF/UHF radio
- Electronic blanket jamming of control channels of explosive devices
- Provides a minimum protective range of 50m
- Can be used in manpack or vehicular configuration
- Effective in use for protection of mobile column of personnel on foot or moving in vehicles
Applications:
Anti-terror units, bomb squads, VIP protection, protection of convoys, Military forces, SWAT teams, police forces, anti-drug units, riot control units
Specification:
| Total Output Power | 90 Watt |
| Output power | Adjustable could adjust the jamming range |
| Cover Radius | 50-100m(under Signal level ≤-85dBm)@according to the signal density mobile network |
| Jamming type | Sweep Jamming |
| Antenna Type | 5dBi external omni-directional |
| Power Supply | AC adapter (50 to 60Hz/100 to 240V AC –DC27V) |
| Working Time | Not-stop Working(Build-in AC power DC27V and Battery 27V60Ah working 2 hours) |
| Electric Filed (SAR) | Compatible with ICNIRP Standards (Human safe) |
| Operating Temp | -20 to +50℃ |
| Storage Temp | -40 to +60℃ |
| Humidity | 5%-80% |
| Product Dimension(LXWXH) | 380 x 283x 150mm not include antennas |
| Weight | appr.13kg ( not include antennas 7kg and battery about 5kg ) |
Vodasafe MP6plusfor CDMA/GSM/3G2100MHz/4GLTE Cellphone/VHF/UHF Radio
America Type frequency for United States, Canada, Mexico ,S. America.
1.2GGSM/CDMA850MHz:850-894MHz;15W
2.2GGSM1900MHz:1920-1990MHz;5W (2GGSM/CDMA/PCS1900MHz)
3.4GLTE700MHz:700-800MHz;15W
4.3G2100MHz:2100-2170MHz;15W(3GUMTS/WCDMA/TD-SCDMA/CDMA)
5. VHF Radio:135-175MHz; 15W
6. UHF Radio:400-470MHz;15W
Total Output Power: 90W
We could supply customized service by your detail requirements about frequencies setting.
Optional Frequencies:
1.Lojack:173.03MHz
2.CDMA450MHz:430-450MHz/460-470MHz;
3.GPS/GLONASS/GALILEO:L1 L2 L3 L4 L5;
4.Wireless Camera:1.2G ,2.4G,5.8G;
5.Car remote control: 433MHz/315MHz/868MHz;
7. SAT Satellite Phones:1520-1670MHz;
Package contents:
1pcs Signal Jammer
1pcs Battery charger
1pcs manpack bag
6pcs Antenna
